LED Modules
|
▌Main applications
|
|
▌Features
|
|
Street light; Tunnel light; Flood light; High bay; Low bay |
|
● Constant power 190-285V ● High luminance LED Cree/Philips/Samsung/Prolight ● Up to 110-120 lm/W for the module ● Long lifespan more than 50,000hrs ●2KV/4KV/6KV surge protection on board ● PF≧0.98 ● Easy to assemble, easy to replace. |
- Parameter
<
| Part No. | LED | CCT(K) | Power(W) | CRI | Typ.PF | Vf(V) |
Luminous Efficiency (lm/W) |
2θ½[°] |
| LELD-30W-18L-E2 | 4050 | 3000~10000K | 30 | 70 | ≥0.98 | AC220V | 100 | 130 |
| LELD-50W-36L-E2 | 3030 | 3000~10000K | 50 | 80 | ≥0.98 | AC220V | 100 | 130 |
| LELD-50W-18L-4KV | 4050 | 3000~10000K | 50 | 70 | ≥0.98 | AC220V | 100 | 130 |
| LELD-100W-36L-4KV | 4050 | 3000~10000K | 100 | 70 | ≥0.98 | AC220V | 100 | 130 |
| LELD-100W-36L-E2 | 4050 | 3000~10000K | 100 | 70 | ≥0.98 | AC220V | 100 | 130 |
